Coating Pan
Our Coating Pan Machine is engineered to deliver superior performance in coating applications across the pharmaceutical, food, and confectionery industries.
Constructed from high-grade stainless steel, this machine ensures hygienic operation and long-lasting durability.
It features a precisely balanced pan mounted on a dynamically balanced shaft, enabling uniform coating distribution across tablets, candies, and other products.
The pan is tilted for easy loading and unloading, while the blower system provides hot air to enhance coating efficiency and drying speed.
This machine is equipped with a variable-speed drive for pan rotation, allowing adjustment based on coating material and product type.
The attached hot air blower has an adjustable temperature controller for optimized drying conditions.
Designed for batch-wise operation, it minimizes wastage and ensures smooth finishing with every cycle.
Coating Pan
Our Coating Pan Machine is engineered to deliver superior performance in coating applications across the pharmaceutical, food, and confectionery industries.
Constructed from high-grade stainless steel, this machine ensures hygienic operation and long-lasting durability.
It features a precisely balanced pan mounted on a dynamically balanced shaft, enabling uniform coating distribution across tablets, candies, and other products.
The pan is tilted for easy loading and unloading, while the blower system provides hot air to enhance coating efficiency and drying speed.
This machine is equipped with a variable-speed drive for pan rotation, allowing adjustment based on coating material and product type.
The attached hot air blower has an adjustable temperature controller for optimized drying conditions.
Designed for batch-wise operation, it minimizes wastage and ensures smooth finishing with every cycle.
Product Specification
Pan Diameter: 24", 30", 36", 42", 48", 60" (as per model)
Pan Material: SS 304 Food Grade Stainless Steel
Motor Power: 0.5 HP to 2 HP (depending on model)
Blower Heater Capacity: 1 kW to 3 kW
Pan Speed: 5 to 30 RPM (adjustable)
Power Supply: 230V/415V, 50 Hz
Machine Weight: 120 kg to 300 kg (model-dependent)
Applications: Tablet coating, candy polishing, seed coating, etc.
